SMAC HT Series High Torque Brushless DC Motors
SMAC HT Series High Torque Brushless DC Motors are designed for applications that require high torque without high-speed operation. The motor uses SMAC’s printed coil technology and Halbach magnets to provide a flat torque-speed curve.
The HT Series includes HT035 and HT055 models. Both models operate at 48 VDC. The HT035 provides 26 W power and 560 mNm stall torque, while the HT055 provides 37.8 W power and 1,995 mNm stall torque.
The brushless design eliminates brush wear, friction and sparking. Gearbox options of 4:1 and 16:1 are available. Encoder options include 2K and 24K resolution. Built-in servo controller options are also available.
