LTR-A Series Rotary Ball Spline with Support Bearing

The LTR-A Model Rotary Ball Spline with Support Bearing is a compact unit-type ball spline in which the support bearings are directly integrated into the outer surface of the spline nut. Designed to be even more compact than the standard LTR model, the LTR-A enables space-saving installation while providing stable support for combined linear and rotary motion, making it suitable for compact precision automation applications.

Key Features
– Rotary and linear motions
– Rotary type
– Compact
– With support bearing
– Solid spline shaft
– Hollow spline shaft

Spline shaft diameter (mm)
8, 10, 16, 20, 25, 32, 40
